Gotham 8 PDPF Elevations Ice SpecSheet - Manual (Page 3)

GOTHAM ARCHITECTURAL DOWNLIGHTING | 1400 Lester Road Conyers GA 30012 | P 800.315.4982 | gothamlighting.com
© 2006-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 04/10/14. Specifications subject to change without notice. PAGE 3 OF 4
PDPF-8-IcE
PDPF 2/32TRT 8T (1) CF32DT/E/IN/835 LAMP, 2400 RATED LUMENS, 1.1 S/MH, TEST NO. LTL13548
PDPF 2/32TRT 8XF (1) CF32DT/E/IN/835 LAMP, 2400 RATED LUMENS, 1.3 S/MH, TEST NO. LTL13549
PH
OTO
M
ET
RY
Distribution Curve Distribution Data Output Data Coefficient of Utilization Illuminance: Single Luminaire 30” Above Floor
8” PDPF
Elevations ®
Performance Downlight ICE™ Pendant, Horizontal Triple-Tube Lamp
Zone Lumens % Lamp
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 180°
0° - 180°
756.8
1127.9
1545.7
1645.2
0.0
1645.2
15.8
23.5
32.2
34.3
0.0
*34.3
*Efficiency
0° 10° 20° 30°
40°
50°
60°
70°
80°
90°
200
400
600
800
1000
pf
pc
pw
20%
80% 70% 50%
50% 30% 50% 30% 50% 30%
1
2
3
4
5
6
7
8
9
10
.37
.34
.30
.28
.25
.23
.21
.20
.18
.17
.36
.32
.28
.25
.23
.21
.19
.17
.16
.15
.36
.33
.30
.27
.25
.23
.21
.20
.18
.17
.35
.31
.28
.25
.23
.21
.19
.17
.16
.15
.35
.32
.29
.27
.24
.22
.21
.19
.18
.17
.34
.30
.27
.25
.22
.20
.19
.17
.16
.15
From 0° Ave Lumens
0
5
15
25
35
45
55
65
75
85
90
1042
1048
983
839
597
352
158
65
24
5
0
99
276
382
371
272
146
67
27
6
50% beam angle
56.3°
10% beam angle
92.9°
Mount
height
Inital fc
at beam
center
Beam
diameter
fc at
beam
edge
Beam
diameter
fc at
beam
edge
8
10
12
14
16
34.4
18.5
11.5
7.9
5.7
5.9
8.0
10.2
12.3
14.5
17.2
9.3
5.8
3.9
2.9
11.6
15.8
20.0
24.2
28.4
3.4
1.9
1.2
0.8
0.6
Zone Lumens % Lamp
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 180°
0° - 180°
1078.8
1639.4
2050.8
2083.8
0.0
2083.8
22.5
34.2
42.7
43.4
0.0
*43.4
*Efficiency
0° 10° 20° 30°
40°
50°
60°
70°
80°
200
400
600
800
1000
1200
1400
pf
pc
pw
20%
80% 70% 50%
50% 30% 50% 30% 50% 30%
1
2
3
4
5
6
7
8
9
10
.48
.44
.40
.37
.34
.31
.29
.27
.25
.23
.46
.41
.37
.34
.31
.28
.26
.24
.22
.20
.47
.43
.39
.36
.33
.31
.29
.26
.25
.23
.45
.41
.37
.34
.31
.28
.26
.24
.22
.20
.45
.41
.38
.35
.32
.30
.28
.26
.24
.23
.44
.40
.36
.33
.30
.28
.25
.23
.22
.20
From 0° Ave Lumens
0
5
15
25
35
45
55
65
75
85
90
1218
1270
1352
1266
895
455
64
22
8
2
0
124
381
575
561
340
72
22
9
2
50% beam angle
65.0°
10% beam angle
92.7°
Mount
height
Inital fc
at beam
center
Beam
diameter
fc at
beam
edge
Beam
diameter
fc at
beam
edge
8
10
12
14
16
40.3
21.7
13.5
9.2
6.7
7.0
9.5
12.1
14.6
17.2
20.1
10.8
6.7
4.6
3.3
11.5
15.7
19.9
24.1
28.3
4.0
2.2
1.3
0.9
0.7
PHOTOMETRY NOTES
• Tested to current IES and NEMA standards under stabilized laboratory conditions.
• Actual performance may differ as a result of end-user environment and application.
• Consult factory or IES file for microgroove baffle, black cone or other photometric reports.
