9” cfvl lensed cylinders – Gotham 9 CFVL Lensed Cylinders SpecSheet User Manual
Page 2
PAGE 2 OF 3
CFVL-9-LENSED
© 2006-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 12/19/13. Specifications subject to change without notice.
9” CFVL
Lensed Cylinders
Wet Location, Vertical Lamp, Double Twin-Tube (DTT) or Triple-Tube (TRT), 8” Aperture
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
DIM
EN
SIO
N
AL D
AT
A
Reflector Aperture: 8 (20.3)
Housing Diameter: 9-3/8 (23.8)
A =
8 (20.3)
B =
5-5/16 (13.5)
C =
3-1/4 (8.3)
D =
12-1/2 (31.8)
Wall Mount Dimensions
16
(40.6)
A
C
D
B
A
B
C
D
