© 2010-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 09/04/13. Specifications subject to change without notice.
PAGE 2 OF 3
LGFI-R-8
DIM
EN
SIO
N
AL D
AT
A
8” LGFI
Round Lens
Wet Location, Horizontal DTT or TRT Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
9-1/4
(23.5)
13-7/8
(35.3)
Aperture:
7-7/8 (20)
Ceiling Opening:
8-5/8 (21.9)
Overlap Trim:
9-1/4 (23.5)
7-9/16
(19.3)
