PDRDF-8-OPEn
8” PDRDF
Recessed Dish/Glass Shade
Triple-Tube and Double Twin-Tube Lamps
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
DIM
EN
SIO
N
AL D
AT
A
Dish Aperture:
21 (53.4)
Ceiling Opening: 21-3/16 (53.8)
Overlap Trim:
22-3/8 (56.8)
7-5/16
(18.5)
10-9/16
(26.8)
2-1/16 (5.2)
23-3/8
(59.4)
25-1/4 (64.1)
