Gotham 4 DPH PAR Directional SpecSheet User Manual
Page 2
© 2007-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 07/23/13. Specifications subject to change without notice.
PAGE 2 OF 3
DPH-4-PAR-DIR
DIM
EN
SIO
N
AL D
AT
A
N
OT
ES
4” DPH
PAR Directional
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
ORDERING NOTES
1.
Not available with finishes.
2.
Available in 120V or 277V only.
3.
For compatible RELOC systems, refer to
4.
QRS, QRSTD and EC not available in combination or with filter holders.
5.
Above ceiling access required for ballast maintenance.
6.
.
18-1/4
(46.4)
18-3/4
(47.6)
Aperture:
4-3/8 (11.1)
Ceiling opening:
5-1/8 (13.0)
Overlap trim:
5-7/16 (13.8)
9-1/2
(24.1)
DIMENSIONAL NOTES
•
Magnetic ballast shown. HEB: 16 (40.6) X 15 1/8 (38.4)
