Gotham 4 SQDLWTH Lensed Wallwash SpecSheet User Manual
Page 2
© 2008-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 02/06/13. Specifications subject to change without notice.
PAGE 2 OF 3
SQDLWTH-4-WSH
4” SQDLWTH
Lensed Wallwash
T4/T6 Lamp
All dimensions are inches (centimeters) unless otherwise noted.
PH
OTO
M
ET
RY
DIM
EN
SIO
N
AL D
AT
A
9-7/8
(25.0)
Ceiling opening:
5-1/8 (13.0)
Overlap trim:
5-3/4 (14.6)
Aperture opening: 4-3/8 (11.1)
15-3/8
(39)
17-3/16
(43.7)
