ATH-4-OPEN
4” ATH
T4/T6 Downlight
Ceramic Metal Halide Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
Aperture:
4-3/8 (11.1)
Ceiling Opening: 5-1/16 (12.9)
Overlap Trim:
5-7/16 (3.8)
9-13/16
(24.9)
15-3/16
(38.6)
15-9/16
(39.5)
DIM
EN
SIO
N
AL D
AT
A
