13” ch

background image

Luminaire Type:
Catalog Number
(autopopulated):

GOTHAM ARCHITECTURAL DOWNLIGHTING | 1400 Lester Road Conyers GA 30012 | P 800.315.4982 | gothamlighting.com

© 2008-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 12/05/13. Specifications subject to change without notice.

PAGE 1 OF 3

CH-13-OPEn-ED17

Gotham Architectural Downlighting
HID Surface Downlights

13” CH

Cylinders

Metal Halide or High Pressure Sodium Lamp
12” Aperture

OPTICAL SYSTEM

Self-flanged, semi-specular or matte-diffuse reflector.

Clear tempered lens standard.

HOUSING

Heavy gauge, aluminum housing with no visible seam. Matte white textured
polyester powder paint finish standard.

Top reveal for floating luminaire appearance. Provided with safety chain between
reveal and housing on ceiling and pendant units for hands free wiring connections.

MOUNTING

Ceiling mount must be anchored to structural support.

Wall mount must be anchored to structural support. See bracket dimensions to
determine size and construction required.

Pendant mount entry provided for 3/8” National Pipe Thread stem. Additional
pendant options available (see accessories). Wires supplied by others.

ELECTRICAL SYSTEM

Mogul or medium-base porcelain socket with nickel-plated screw shell.

Removable, pre-wired power module with high power factor, pulse start, core-
and-coil ballast, integral fusing and quick disconnect plug.

LISTING

Fixtures are UL Listed for damp locations. Listed and labeled to comply with
Canadian standards.

WARRANTY

1-year limited warranty. Complete warranty terms located at

www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx

EXAMPLE: CH13 100M 12AR 120 FCM DWHG

Series

Wattage/Lamp

1,2

Aperture/Trim color Finish

Voltage

Mounting

5

CH13

Metal halide
70M

MED

100M

MED

175M

MOG

250M

MOG

High pressure sodium
70S

MOG

100S

MOG

150S

MOG

Color-correct metal halide

3

50MHC

MED

70MHC

MED

100MHC

-

MED

12AR

Clear

12PR

Pewter

12WTR Wheat
12BR

Black

12WR

White

(blank) Semi-specular
LD

Matte-diffuse

MVOLT

4

120
208
240
277
347

FCM

Ceiling mount

WM

Wall mount

PM

6

Pendant 3/8” thread mount

Options

SF

7

Single fuse

QRS

8

Quartz restrike system

QRSTD

8

QRS with time delay

EC

9

Emergency circuit

WLP

Lamp (shipped separately)

Architectural Colors - Powder Paint

10

DWHG

Matte white (standard)

DDB

Dark bronze

DBL

Black

DWH

Gloss white

DMB

Medium bronze

DNA

natural aluminum

DSS

Sandstone

DGC

Charcoal grey

DTG

Tennis green

DBR

Bright red

DSB

Steel blue

ACCESSORIES order as separate catalog numbers (shipped separately)

CYS

11

3/8” stem and canopy with 5° “hang straight” swivel

CRS

11

3/8” stem and canopy with 45° swivel

FE
