LGH-10-ROund-LEnS
DIM
EN
SIO
N
AL D
AT
A
10” LGH
Round Lens
Wet Location, Vertical Metal Halide Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
20-1/8
(51.1)
23-3/4
(60.3)
Aperture:
9-3/4 (24.8)
Ceiling Opening: 10-1/2 (26.7)
Overlap Trim:
10-7/8 (27.6)
14-1/4
(36.2)
