AHI-AHWI-8-OPEn
AHI/AHWI
20.3cm (8”) Open/Wallwash Reflector
Metal Halide Lamp
PH
OTO
M
ET
RY
All dimensions are centimeters (inches) unless otherwise noted.
DIM
EN
SIO
N
AL D
AT
A
EL
EC
TR
IC
AL
23.5
(9-1/4)
34.8
(13-11/16)
29.2
(11-1/2)
CE CERTIFIED
Aperture:
20.1 (7-7/8)
Ceiling opening: 21.9 (8-5/8)
Overlap trim:
23.5 (9-1/4)
23.4
(9-1/4)
39.7
(15-5/8)
29.8
(11-11/16)
UL LISTED
Annual*
Energy
Cost
$4.05
$4.44
(1) 100M
(1) 100M
Lamp
Lumens
8700
1200
1.00
1.00
Input
Watts
110
169
*
Comparative yearly lighting energy cost per 1000 lumens
LER.DOL
59
54
Ballast
Factor
ENERGY
(Calculated in accordance eith NEMA standard LE-5A)
Lamps
