Gotham 4 A Open Reflector SpecSheet User Manual
Page 2
© 2005-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 06/26/13. Specifications subject to change without notice.
PAGE 2 OF 3
A-4-OPEN
DIM
EN
SIO
N
AL D
AT
A
4” A
Open Reflector
A19 or BT15 Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
Aperture:
4-5/16 (11.0)
Ceiling opening:
5-1/8 (13.0)
Overlap trim:
5-7/16 (13.8)
8-7/16
(21.4)
13-5/8
(34.6)
15-7/8
(40.3)
