CWU-7-OPEn
7” CWU
Up/Down, Wall-Mounted Cylinder
PAR38, R40 Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
DIM
EN
SIO
N
AL D
AT
A
Aperture:
5-1/2 (14.0)
Housing Diameter:
6-5/8 (16.8)
Housing Height:
22 (55.9)
A
C
D
B
A =
11 (27.9)
B =
5-1/8 (13.0)
C =
3-1/4 (8.3)
D =
9-7/8 (25.1)
Wall Mount Dimensions
A
B
C
D
