Gotham 10 LGZ Round Lens SpecSheet User Manual
Page 2
© 2005-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 10/01/13. Specifications subject to change without notice.
PAGE 2 OF 3
LGZ-10-ROund-LEnS
DIM
EN
SIO
N
AL D
AT
A
10” LGZ
Round Lens
Wet Location, Horizontal A23 Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
17
(43.2)
17-1/4
(43.0)
Aperture:
9-3/4 (24.8)
Ceiling Opening:
10-1/2 (26.7)
Overlap Trim:
11-1/8 (28.3)
8-5/8
(21.9)
