SQDP-6
DIM
EN
SIO
N
AL D
AT
A
6” SQDP
Square Adjustable
PAR Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
19-3/16
(50.4)
17-3/16
(45.3)
Ceiling opening:
6-7/8 (17.5)
Overlap trim:
7-1/2 (19.1)
Aperture opening:
5-15/16 (15.1)
13-7/8
(35.3)
