Gotham 6 SQP Square Open Reflector SpecSheet User Manual
Page 2
© 2009-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/30/13. Specifications subject to change without notice.
PAGE 2 OF 3
SQP-6
DIM
EN
SIO
N
AL D
AT
A
6” SQP
Square Open Reflector
Vertical, PAR Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
19-7/8
(50.5)
17-9/16
(44.7)
Ceiling opening:
6-5/8 (16.8)
Overlap trim:
7-3/16 (18.3)
Aperture opening:
5-15/16 (15.1)
12-1/8
(30.8)
