8” AFVI/AFVWI
Open/Wallwash
Vertical DTT or TRT Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
15-5/16
(39.0)
19-1/4
(23.4)
Aperture:
7-7/8 (20)
Ceiling opening:
8-5/8 (21.9)
Overlap trim:
9-1/4 (23.5)
10-1/16
(25.5)
