6” afi/afwi open/wallwash – Gotham 6 AFI_AFWI Open_Wallwash SpecSheet User Manual
Page 2
© 2010-2013 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 06/26/13. Specifications subject to change without notice.
PAGE 2 OF 3
AFI-AFWI-R-6
DIM
EN
SIO
N
AL D
AT
A
6” AFI/AFWI
Open/Wallwash
Horizontal DTT or TRT Lamp
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
7-1/2
(19.1)
14-5/16
(36.3)
Aperture:
6-1/4 (15.9)
Ceiling Opening: 6-7/8 (17.5)
Overlap Trim:
7-1/2 (19.1)
7-1/8
(18.0)
