4” DLV

Adjustable Downlight

Open Cone, Max 75 Watt

LAMP PERFORMANCE DATA
All data was calculated from each lamp manufacturer’s published data and is subject to normal lamp variations. Maximum footcandle is usually at the aiming point, but not
always on wider spread lamps. Lamp data supplied by manufacturers is approximate, and individual lamp performance may vary.

45º

aiming

angle

60º

aiming

angle

H

V1

V2

Formula for other distances and aiming angles.

45º

.354

6

7

8

9 10

50º

.266

7

8 10 11 12

55º

.189

9 10 11 13 14

60º

.125

10 12 14 16 17

65º

.076

13 15 18 19 21

70º

.040

17 19 22 25 28

75º

.017

22 26 30 34 37

Aiming

angle Cos

3

Feet

down from ceiling (V)

Feet

out

6

7

8

9 10

MBCP x Cos

3

(aiming angle)

H

2

(distance from wall squared)

fc =

ACCENT LIGHTING ANGLE PERFORMANCE DATA

DISTANCE LAMP TO LIGHTED SURFACE

2 FEET 4 FEET

DISTANCE DOWN TO AIMING POINT

V1 (FT) 2

V2 (FT) 7

Beam

Lamp No.

Watts Type

MFG. Width (°) MBCP Aiming Angl e Beam

Aiming Angle Beam

to

45°

Length Width

60°

Length Width

50% MBCP

FT-CANDLES

FT-CANDLES

MR-16

ESX

20

NSP GE/SY/PH

15

3600

318

1.1

0.7

28

4.4

2.1

BAB

20

FL GE/SY/PH

40

525

46

3.4

2.1

4

19.3

5.8

EXT

50

NSP GE/SY/PH

13

10200

902

0.9

0.6

80

3.8

1.8

EXZ

50

NFL

GE/SY

26

3400

301

2.0

1.3

27

8.8

3.7

EXN

50

FL GE/SY/PH

40

1850

164

3.4

2.1

14

19.3

5.8

EYJ

71/65

MFL

GE/SY

24

4900

433

1.8

1.2

38

7.9

3.4

EYC

71/65

FL

GE/SY

36

2100

186

2.9

1.8

16

15.2

5.2

MR-11

FTB

20

SP

SY/PM

10

5000

442

0.7

0.5

39

2.9

1.4

FTD

20

NFL

SY

30

600

53

2.3

1.5

5

10.9

4.3

FTE

35

SP

SY/PM

10

6500

575

0.4

0.5

51

2.9

1.4

FTH

35

NFL

SY/PM

30

1300

115

2.3

1.5

10

10.9

4.3

ALR-12

GBD

20

NSP

PH

6

7000

619

0.4

0.3

55

1.7

0.8

GBE

20

SP

PH

18

1500

133

1.3

0.9

12

5.5

2.5

GBF

20

FL

PH

32

750

66

2.5

1.6

6

12.2

4.6

ALR-18

GBJ

50

SP

PH

10

13000

1149

0.7

0.5

102

2.9

1.4

GBK

50

NFL

PH

25

1900

468

1.9

1.3

15

8.3

3.5

AR-70

20AR70/8/SP

20

SP

SY

8

7000

619

0.6

0.4

55

2.3

1.1

20AR70/25/FL

20

FL

SY

25

850

75

1.9

1.3

7

8.3

3.5

50AR70/8/SP

50

SP

SY

8

15000

1326

0.6

0.4

117

2.3

1.1

50AR70/25/FL

50

FL

SY

25

2000

177

1.9

1.3

16

8.3

3.5

LOCATION OF ACCENT LUMINAIRE TO PROVIDE AIMING PT. 5.5' ABOVE THE FLOOR

Clg. Ht. (ft)

60° Aiming Angle

45° Aiming Angle

Out (H) Down (V2)

Out (H) Down (V1)

8

1.5 2.5

2.5 2.5

9

2.0 3.5

3.5 3.5

10

2.5 4.5

4.5 4.5

PHOTOMETRY NOTES

Tested to current IES and NEMA standards under stabilized laboratory conditions.

Actual performance may differ as a result of end-user environment and application.

Consult factory or IES file for microgroove baffle, black cone or other photometric reports.
