DLWH-6-LENSED-PAR
DIM
EN
SIO
N
AL D
AT
A
6” DLWH
Lensed Wallwash
PAR30 or PAR38 Metal Halide Lamp
All dimensions are inches (centimeters) unless otherwise noted.
PH
OTO
M
ET
RY
19-11/16
(50.0)
25-5/8
(65.1)
Aperture:
6-1/4 (15.9)
Ceiling opening:
6-7/8 (17.5)
Overlap trim:
7-5/8 (19.4)
10-9/16
(26.8)
