Gotham Ecos Square Trim - Manual

CJ520363 Rev. B
©2010 Acuity Brands Lighting, Inc.
All Rights Reserved.
11/10 1 of 1
SAVE THESE INSTRUCTIONS
Upon receipt, thoroughly inspect for any freight
damage which should be brought to the attention of
the delivery carrier. Compare the catalog
description listed on the packing slip with the label
on the carton to ensure you have received the
correct merchandise.
INSTALLATION INSTRUCTIONS
Square Trim
IMPORTANT SAFETY INFORMATION
For Your Protection, Read Carefully
Warning: Risk of fire. Do not install
insulation within 3 inches of fixture
sides or wiring compartment, nor above
fixture in such a manner as to entrap
heat.
Electric current can cause painful
shock or serious injury unless
handled properly. For you safety,
always remember the following:
• Turn off the supply power.
• Ground the fixture to avoid potential
electrical shocks.
• Do not handle an energized fixture or
energize any fixture with wet hands,
when standing on a wet or damp
surface, or in water.
1. Install safety chain. (See Figure 1)
2. Install trim by aligning retention tabs with springs located on mounting frame.
Push trim into housing assuring it is fully engaged and flush with the ceiling. (See
Figure 2)
CLEANING AND MAINTENANCE
Apply window cleaner to soft non-abrasive cloth to clean luminaire.
CAUTION: DO NOT SPRAY CLEANER DIRECTLY INTO LUMINAIRE.
Figure 1
Figure 2
