© 2009-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 04/08/14. Specifications subject to change without notice.
PAGE 2 OF 3
ECSSW-6-LENSED
6” Ecos™ Square
Lensed Wallwash
Solid-State Lighting
PH
OTO
M
ET
RY
DIM
EN
SIO
N
AL D
AT
A
DIMENSIONAL NOTES
•
Minimum of 9” required above fixture for non-accessible ceilings.
All dimensions are inches (centimeters) unless otherwise noted.
7-1/4
(18.4)
Aperture:
6 (15.2)
Ceiling opening: 6-5/8 (16.8)
Overlap trim:
7-3/16 (18.3)
19-7/8
(50.5)
18-5/8
(47.3)
