EVO-6-DECO
DIM
EN
SIO
N
AL D
AT
A
6” EVO
Drop Luminous Ring/Disk
Solid-State Lighting
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
1 [2.5]
8 [20.3]
Aperture: 6-1/4 (15.9)
Ceiling Opening: 7-1/8 (18.1)
Overlap Trim: 7-1/2 (19.1)
7 9
16 [19.1]
15 1
16 [38.3]
15 78 [40.3]
