PDLFV-8-OPEN
8” PDLFV
Candéo® LED Open Reflector
Vertical Triple-Tube Lamp
PH
OTO
M
ET
RY
DIM
EN
SIO
N
AL D
AT
A
All dimensions are inches (centimeters) unless otherwise noted.
8-1/4
(21.0)
5
(12.7)
Aperture: 7-7/8 (20)
Ceiling Opening: 8-7/8 (22.5)
Overlap Trim: 9-1/4 (23.5)
15 -3/4
(40.0)
14-1/4
(36.2)
