Product dimensions tpt101 twisted pair transmitter – Extron Electronics TPT101_TPR101 User Guide User Manual
Page 20
18
TPT101 / TPR101 Operation Manual - Preliminary 8/18/2003
© 2003 - EXTRON, Inc.
PRODUCT DIMENSIONS
TPT101 TWISTED PAIR TRANSMITTER
Video / Audio Input
TPT101 Twisted Pair A/V Transmitter
Auto
Power
front view
bottom view
right side view
back view
top view
0.16" Ø
(2 Places)
2.75"
4.50"
0.43"
0.43"
1.65"
1.89"
0.60"
3.30"
0.60"
4.50"
1.59"
0.10"
0.85"
0.85"
1.98"
0.85"
1.69"
