Vkm01 application diagram – Extron Electronics VKM01_02_03 User Manual
Page 9
5
VKM01 Video / Keyboard / Mouse Extender System Operation Manual - Preliminary 02/18/00 ©2000 - INLINE, INC.
VKM01 APPLICATION DIAGRAM
SERIAL MOUSE
MOUSE
VIDEO
KEYBOARD
TO PERIPHERALS
MOUSE
VIDEO
KEYBOARD
TO COMPUTER
TECHNICAL SUPPORT:
(800)882-7117
(714)921-4100
www.inlineinc.com
MADE IN U.S.A
CAT 5 LINK
MOUSE
VIDEO
KEYBOARD
OUTPUT
TECHNICAL SUPPORT:
(800)882-7117
(714)921-4100
www.inlineinc.com
MADE IN U.S.A
CAT 5 LINK
AGC
+
POWER
9VDC; 0.5A
EXTENSION
CAT 5 CABLE
REMOTE KEYBOARD/MOUSE
AND MONITOR
LOCAL KEYBOARD/MOUSE
AND MONITOR
COMPUTER
VKM02 TRANSMITTER
VKM03 RECEIVER
