Specifications
VKM01 Video / Keyboard / Mouse Extender System
VKM02 Local Module - Computer CPU Connections
Video
(1) 15-Pin HD Female - Supports VGA
signals at resolutions up to 1600 x 1200
Keyboard
(1) 6-Pin Mini DIN Female
Mouse
(1) 6-Pin Mini DIN Female
CAT5 Link
(1) RJ45 Female
VKM02 Local Module - Peripheral Connections
VGA Video Out
(1) 15-Pin HD Female
Keyboard
(1) 6-Pin Mini DIN Female for PS/2 Type Keyboards
(PC / AT Keyboard Support via Optional Adapter / Cable)
Mouse
(1) 6-Pin Mini DIN Female for PS/2 Mouse
(1) 9-Pin D Female for Serial Mouse
VKM03 - Remote Module Connections
VGA Video Out
(1) 15-Pin HD Female
Keyboard
(1) 6-Pin Mini DIN Female for PS/2 Type Keyboards
(PC/AT Keyboard Support via Optional Adapter)
Mouse
(1) 6-Pin Mini DIN Female for PS/2 Mouse
CAT5 Link
(1) RJ45 Female
Power Supply
9VDC, 500mA Extender Adapter (Included)
General
Shipping Weight
5 lbs. / 2.3 kg.
Product Weight
2.5 lbs. / 1.1 kg.
Dimensions - VKM02
1.65” x 5.6” x 3.75” / 4.2 cm x 14.2 cm x 9.5 cm
Dimensions - VKM03
1.65” x 5.6” x 3.75” / 4.2 cm x 14.2 cm x 9.5 cm
Regulatory Approvals
UL1950, CAN/CSA-22.2 No. 950, Third Edition
CE: EN55022 (1987), EN50081-1 (1991)
EN50082-1 (1992 and 1994), EN60950-92
VKM01 Video / Keyboard / Mouse Extender System - Parts Included
(1)
VKM02 Local Module
(1)
VKM03 Remote Module
(1)
IN9204-1 9VDC; 500mA External Power Adapter (for U.S. applications only)
(1)
IN8006M VGA Cable, 15-Pin HD Male to 15-Pin HD Male, 6’ Long - Connects
CPU VGA Port to VKM02
(1)
VN576-L6 PS/2 Keyboard Cable, 6-Pin Mini DIN Male to Male, 6’ Long -
Connects CPU Keyboard Port to VKM02
(1)
VN576-L6 PS/2 Mouse Cable, 6-Pin Mini DIN Male to Male, 6’ Long -
Connects CPU Mouse Port to VKM02
(1) IN9333 Adjustment Tool
(1) Operation Manual
