Remote Contr
ol, cont’d
4-4
Cr
ossPoint / MA
V Matrix Switchers • Remote Contr
ol
4-5
Refer also to the
Cr
ossPoint 450 Plus / MA
V Plus User’
s Manual
at
www
.extron.com
.
Refer also to the
Cr
ossPoint 450 Plus / MA
V Plus User’
s Manual
at
www
.extron.com
.
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional description
Create ties
N
• Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%4*24$.
•
The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1!, 02*02&, or 003*003%).
N
When you create a tie where
X!
= 00, you tie no input to the specified output (
X@
) (untie
X@
).
When you create a tie where
X@
= 00, you untie all outputs from input
X!
.
N
The
& tie command for RGB and the % tie command for video can be used interchangeably.
N
The
& read tie command for RGB and the % read tie command for video can be used interchangeably.
Tie input
X!
to output
X@
,
video
and audio
X!
*
X@
!
Out
X@
•
In
X!
•
All
]
Tie input
X!
‘s video and audio to output
X@
.
Example:
1*3!
Out03•In01•All
]
Tie input 1 video and audio to output 3.
Tie input
X!
to output
X@
, RGBHV
X!
*
X@
&
Out
X@
•
In
X!
•
RGB
]
Tie RGB only (video breakaway).
Example
(see 3rd Note, above):
10*4&
Out04•In10•RGB
]
Tie input 10 RGB to output 4.
Tie input
X!
to output
X@
, video
X!
*
X@
%
Out
X@
•
In
X!
•
Vid
]
Tie video only (video breakaway).
Example
(see 3rd Note, above)
7*5%
Out05•In07•Vid
]
Tie input 7 video to output 5.
Tie input
X!
to output
X@
, audio
X!
*
X@
$
Out
X@
•
In
X!
•
Aud
]
Tie audio only (audio breakaway).
Example:
24*04$
Out04•In24•Aud
]
Tie input 24 audio to output 4.
Read RGB output tie
X@
&
X!]
RGBHV input
X!
is tied to output
X@
.
Read video output tie
X@
%
X!]
Video input
X!
is tied to output
X@
.
Read audio output tie
X@
$
X!]
Audio input
X!
is tied to output
X@
.
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional description
Video and audio mute commands
RGB/video mute
X@
*1B
Vmt
X@
*1
]
Mute output
X@
RGB (video off).
RGB/video unmute
X@
*0B
Vmt
X@
*0
]
Unmute output
X@
RGB (video on).
Read RGB/video mute
X@
B
X#]
1 = mute on, 0 = mute off.
Global RGB/video mute
1*B
Vmt1
]
Mute all RGB outputs.
Global RGB/video unmute
0*B
Vmt0
]
Unmute all RGB outputs.
Audio mute
X@
*1Z
Amt
X@
*1
]
Mute output
X@
audio (audio off).
Audio unmute
X@
*0Z
Amt
X@
*0
]
Unmute output
X@
audio (audio on).
Read audio mute
X@
Z
X#]
1 = mute on, 0 = mute off.
Global audio mute
1*Z
Amt1
]
Mute all audio outputs.
Global audio unmute
0*Z
Amt0
]
Unmute all audio outputs.
View output mutes
E
VM
}
X$
1
,
X$
2
, ...
X$
n
]
Each
X$
response is the mute status of an output,
starting from output 1.
n
= the maximum number of outputs for this model.
Example:
CrossPoint 450 Plus 6432 HVA
E
VM
}
Mut02202000000000000000000000000000
]
Output 2, 3, and 5 audio is muted. All other
outputs are unmuted.
N
The “Mut” portion of the response appears only when the switcher is in Verbose mode 3. See the Verbose mode command on page 4-.
N
X!
= Input number
00 – (maximum number of inputs for your model) (00 = untie)
X@
= Output number
00 – (maximum number of outputs for your model) (00 = untie all outputs)
N
X@
= Output number
01 – (maximum number of outputs for your model)
X#
= Mute
0 = off (unmuted)
1 = on (muted)
X$
= Video/audio mute:
0 = no mutes
1 = video mute
2 = audio mute
