CrossPoint / MAV Matrix Switchers • Installation
Installation, cont’d
2-6
CrossPoint 450 Plus / MAV Plus Matrix Switchers
Refer also to the CrossPoint 450 Plus / MAV Plus User’s Manual at
www.extron.com
.
Power connection
k
Power — Plug the switcher into a grounded AC source.
Front Panel Configuration Port
CONTROL
VIEW
ESC
AUDIO
VIDEO
I/O
CONTROL
VIEW
ESC
AUDIO
VIDEO
I/O
CONTROL
VIEW
ESC
CROSSPOINT 450 PLUS SERIES
ULTRA WIDEBAND MATRIX SWITCHER
AUDIO
VIDEO
I/O
PRIMARY
REDUNDANT
POWER SUPPLY
I/O CONFIG
12
l
Configuration port —
If desired, connect a control system
or computer to the front panel Configuration (RS-232) port.
Use an optional 9-pin D to 2.5 mm mini jack TRS RS-232
cable, part #70-335-01.
3
Chapter Three
Front Panel Operation
Creating.a.Tie
Saving.or.Recalling.a.Preset
Setting.the.Front.Panel.Locks.(Executive.Modes)
Viewing.and.Adjusting.the.Input.Audio.Level.and.Output.Volume
Viewing.Ties.(and.Muting.Outputs)
