Page 13: Chapter four

CrossPoint / MAV Matrix Switchers • Front Panel Operation
Front Panel Operation, cont’d
3-6
CrossPoint 450 Plus / MAV Plus Matrix Switchers
Refer also to the CrossPoint 450 Plus / MAV Plus User’s Manual at
www.extron.com
.
Viewing Ties (and Muting Outputs)
1
.
Press the View button. Output buttons light for outputs
that have no ties established.
N
If an output button blinks, that output is muted.
2
.
Press an input button. The buttons for all tied outputs
light (amber for video and audio, green for video only, and
red for audio only).
3
.
Press an output button. The buttons for the tied input and
all tied outputs light.
4
.
If you want to toggle a mute on and off
, press and hold
the output button for 2 seconds.
5
.
Press the View button. All input and output buttons return
to an unlit state.
4
Chapter Four
Remote Control
Selected.SIS.Commands
Installing.and.Starting.the.Control.Program
Accessing.the.HTML.Pages
