Initial Configuration
Before use, configure the touchpanel, using the on-screen menus.
1.
Press the Menu button once (
e
in the figure on page 6). The Main menu screen opens.
Main
Vol
Time
IP
Exit
Down
Up
Down
On
On
Up
Sleep timer: 005 Min
Backlight: 073%
Auto
Backlight
Vid
LED
Backlight
2.
Touch an on-screen button to highlight and select that option (the button turns green with a yellow border).
3.
Use the
Up
and
Down
buttons to adjust the value. Some options have a single button and toggle between
Off
and
On
when
the button is pressed.
There are five different screens (
Main
,
Volume
,
Time
,
Network
, and
Video
) that can be selected by pressing the appropriate button
at the left side of the screen. There is also an
Exit
button at the bottom right corner of the screen for saving changes and leaving
the menus.
Use the screens to adjust the following options (for more information, see the TLP 350CV User Guide).
Main — Adjusts the
Sleep timer
,
Backlight
,
Auto Backlight
, and
LED Backlight
functions.
Volume — Adjusts the
Master
,
Click
,
Sounds
, and
Line In
volume settings.
Time — Sets the correct time and date.
IP — (Network configuration) Sets the
IP Address
and the
Subnet Mask
, and enables or disables Dynamic Host Configuration
Protocol.
Video — Provides a small video preview window and the controls to adjust the video contrast, color, brightness, and tint.
