Command/response table for special function SIS commands, continued
Command
ASCII Command Response
X?
and
Y?
values
(host to MLC)
(MLC to host)
and additional descriptions
Front panel button LED control
24
X?
*
Y?
*51 #
Lmp
Y?
*
X?
X?
is the LED state,
Y?
is which projector power,
input, or room/function button
to control. See the list of values
at left.
0 = all LEDs are off
1 = green LED is on
2 = red LED is on
3 = green & red LEDs are
on (button glows amber)
4 = slowly blinking green
5 = slowly blinking red
6 = slowly blinking amber
7 = fast blinking green
8 = fast blinking red
9 = fast blinking amber
1 = power on button
2 = power off button
9 = input button 1
10 = input button 2
11 = input button 3
12 = input button 4
X
?
Y
?
values
values
Query button LED control status
Y?
* 51 #
X?
See the variables for the
command shown above.
Front panel lockout
Lock out input selection during power-on/power off
24
X?
* 53 #
PwrLock *
X?
For
X?
:
0 = off (default)
1 = on
This command applies to input selection buttons in the switching rotation only (input buttons that are not controlled
by scripts).
Input switching lockout duration
24
X?
* 54 #
IODelay *
X?
This command locks out
(prevents changes to) input
switching for the specified
duration after an input has been
switched.
X?
is the lockout
duration of from 0 to 65535, in
20 ms steps.
1 = 20 ms, 2 = 40 ms, 3 = 60 ms,...
65535 = 1,310,700 ms = 21.845
minutes. Default = 25 = 0.5 s.
This command applies to input selection buttons in the switching rotation only (input buttons that are not controlled
by scripts).
Example:
25*54#
IODelay*25
Inputs cannot be switched for
0.5 seconds after an input
change.
Enable PIN
24
X?
* 60 #
PINEnable *
X?
For
X?
,
0 = personal identification
number (PIN) access is enabled
for all levels (administrator and
user)
1 = administrator PIN only is
enabled
2 = PIN access is disabled
(default)
PIN access can be used only while display power is off.
Set PIN
24
X?
*
Y?
* 61 #
PINNum *
X?
*
Y?
For
X?
,, 0 = administrator level,
1 = user level.
For
Y?
, the PIN is any 4-digit
combination of the numbers 1
through 4.
Administrator default PIN =
1423.
User default PIN = 0
