SIS ™ Programming and Control, cont’d
MLC 104 Series • SIS ™ Programming and Control 5-12
PRELIMINAR
Y
Command/r
esponse table for SIS commands (continued)
Command
ASCII
(T
elnet)
URL Encoded (W
eb)
Response
Additional description
(host to switcher)
(host to switcher)
(switcher to host)
Serial data port configuration and use
These commands apply to any port that uses RS-232 communication: both 1-way (output) and 2-way (bidir
ectional) RS-232 communica
tion.
Send data string
Esc
X1
*
X1
7
*
X2
0
*
X2
1
RS
X2
W
X1
%2A
X1
7
%2A
X2
0
%2A
X2
1
RS
|
X2
response fr
om command
*
X1
7
*
X2
0
*
X2
1
is optional. If
X1
7
and
X2
0
ar
e not specified, the default values are used. For this command,
X1
7
and
X2
0
must both a) be missing, b) equal zer
o, or c) be nonzer
o.
X1
= specific port number (01 – 99)
01 = r
ear host (Config/RS-232 port)
02 = front panel Config port 03 = slaved switcher (MLS port) 04 = projector port (Pr
oj RS-232/IR)
X2
= command data section.
For W
eb encoding
for
X2
, convert nonalphanumeric characters to hex numbers. A
space (hex = 20) is encoded as %20. A
plus sign (hex = 2B) is
encoded as %2B.
Example:
Esc
04*4*7*3L RS
W04%2A4%2A7%2A3L RS
|
response fr
om command
X1
7
= time in tens of ms for the MLC to wait until r
eceipt of the first r
esponse character before terminating the curr
ent receive
operation (default = 10 = 100 ms, max. = 32767).
The response includes leading zer
os.
X2
0
= time in tens of ms for the MLC to wait
between characters
being received via a serial port befor
e terminating the current r
eceive operation
(default = 2 = 20 ms, max. = 32767). The response includes leading zer
os.
X2
1
= #L
or
#D. The letter parameter is case sensitive (r
equires a capital “D” or capital “L”). The r
esponse includes leading zer
os.
L =
L
ength of the message to be r
eceived.
D =
D
elimiter value.
# = byte count (for L) or a single ASCII character expressed in decimal form (for D). Byte count # can be fr
om 0 to 32767, default = 0. The ASCII decimal delimiter # value can be from 0 to 00255, default = the by
te count.
Examples:
A 3-byte length = 3L. A delimiter of ASCII 0A = 10D.
