MLC 104 Series • SIS

Programming and Control

The syntax for setting a special function for an MLC is

X?

* __ # where

X?

is the value and __ is the

function number. To view a function’s setting, use __#, where __ is the function number. In the
following table the values of the

X?

variable are different for each command/function. These values

are given in the rightmost column.

Command/response table for special function SIS commands
(accessible via RS-232 only)

Command

ASCII Command Response

X?

values

(host to MLC)

(MLC to host)

and additional descriptions

Delay times

Most projectors require a certain amount of time during warm-up and cool-down during which they do not accept
commands. Once you have set the input selction lock during power on/off command (53#, page 5-35), send this
command (1#) to specify the amount of time for the MLC to wait between sending the projector a power-on or power-off
command and when the next input button press can occur.

Power on delay

24

X?

*1 #

WarmUp*

X?

0 = 0 seconds,
1 = 2 seconds,
2 = 4 seconds,
... in 2 second steps up to
150 = 300 seconds (5 minutes).

Example:

8*1#

WarmUp*008

Example: set a 16 second power on delay.

Example:

1#

WarmUp*023

Example:

view the power on delay

setting.

Power off delay

24

X?

*2 #

CoolDown*

X?

0 = 0 seconds,
1 = 2 seconds,
2 = 4 seconds,... in 2 second
steps up to 150 = 300 seconds.

Example:

23*2#

CoolDown*023

Example:

set a 46 second power off

delay.

Power off button delay

24

X?

*22 #

PwrOffDly*

X?

0 = the power off button
requires no hold delay (default),
1 = the power off button
requires a 2-second hold delay
before starting the power-off
sequence.

Audio settings

Limit audio level on display power-on

24

X?

*11 #

VolLimit*

X?

If this feature is enabled, the
maximum initial power-up
volume level does not exceed
the level specified by this
command.
0 = audio off, ...,
20 = default value, ...,
100 = no limit on audio level at
power-on.

The MLC responds with an E14 error code when volume mode = 1 (increment/decrement).

The maximum

X?

is limited by the maximum volume setting (47#). You must set the maximum volume (47#

command) before setting the limit audio level feature (11# command). See page 5-34.

Example:

28*11#

VolLimit*028

Example: limit power-up volume
to 70% of maximum volume.
