Page 9
9
MLM 104 Faceplates • Installation Guide
2.8"
(7.1 cm)
11.0"
(27.9 cm)
SURFACE CUT-OUT
AREA FOR
FURNITURE MOUNT
Cut-Out Template for Extron's MLM 104 6GWP
TEMPLATE IS NOT FULL SIZE.
Top Panel
Location of MLC 104 IP Plus
11.752"
(29.85 cm)
To install the MLC 104 IP Plus
and the MLM 104 6GWP
directly into furniture,
cut along this line.
4.5"
(11.4 cm)
MLM 104 6GWP template
