Page 6
MLM 104 Faceplates Installation Guide, cont’d
MLM 104 Faceplates • Installation Guide
6
MLM 104 LAAP template
2.8"
(7.1 cm)
7.9"
(20.1 cm)
SURFACE CUT-OUT
AREA FOR
FURNITURE MOUNT
10"
(25.4 cm)
Cut-Out Template for Extron's MLM 104 LAAP
TEMPLATE IS NOT FULL SIZE.
To install the MLC 104 IP Plus
and the MLM 104 LAAP
directly into furniture,
cut along this line.
Top Panel
Location of MLC 104 IP Plus
3.15"
(8.0 cm)
.295" (0.75 cm)
.250" (0.64 cm)
