Extron Electronics MLM 104 Faceplates User Manual
Page 5
5
MLM 104 Faceplates • Installation Guide
MLM 104 L and MLC 104 IP Plus L template
.295" (0.75 cm)
.250" (0.64 cm)
6.5"
(16.5 cm)
Cut-Out Template for Extron's MLM 104 L
and MLC 104 IP Plus L
TEMPLATE IS NOT FULL SIZE.
To install MLC 104 IP Plus
and MLM 104 L
directly into furniture,
cut along this line.
Top Panel
2.8"
(7.1 cm)
3.5"
(8.9 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
3.15"
(8.0 cm)
Location of
MLC 104 IP Plus
