MLM 104 Faceplates • Installation Guide
MLM 104 2GWP and MLC 104 IP Plus template
4.6"
(11.7 cm)
Cut-Out Template for Extron's MLM 104 2GWP
and MLC 104 IP Plus
TEMPLATE IS NOT FULL SIZE.
To install MLC 104 IP Plus
and MLM 104 2GWP
directly into furniture,
cut along this line.
Top Panel
2.8"
(7.1 cm)
3.5"
(8.9 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
4.5"
(11.4 cm)
Location of MLC 104 IP Plus
