9
© 1997 - INLINE, INC. IN3526VI OPERATION MANUAL - REV. 2 12/01/98
UNIVERSAL POWER SUPPLY
The IN3526vi switcher employs a universal (switch mode) power supply which automatically adjusts to accept
input voltages worldwide. Input voltages can range between 90 and 260 VAC and the frequency may range from
47 to 63 Hz. The power supply entry module uses an IEC standard male connector for power connection. U.S
domestic units are shipped with a standard IEC female to Edison male power cable.
Changing Fuses
The power entry module includes a quick-change fuse holder. This holder contains the main fuse and a spare. If
the unit does not power-up, check the fuse. If the fuse is blown:
1.
Remove the power cord from the unit.
2. Use a flat blade screwdriver to pull out the fuse holder.
3. Replace the blown fuse with the spare.
4. Replace the spare fuse with a new 125 mA, 250 V fuse.
5. Push the fuse holder back into the casing.
SPECIFICATIONS
IN3526vi Composite/S-Video Switcher
Inputs
Connector type Six BNC female for composite video
Six 4 pin mini-din female for S-Video
Signal Compatibility Composite Video, S-Video (Y/C), Monochrome with Sync
Output
Connector type One BNC female for composite video
One 4 pin mini-din female for S-Video
Bandwidth 300 MHz @ -3dB
Power
Universal Power Supply 90 - 260 VAC; 47 to 63 Hz.
Power Consumption 3 Watts maximum
Fuse 250 VAC, 125mA
Dimensions
Height x Width x Depth 1.75” x 8.5” x 6.5”
Optional Accessories
Stereo Audio Switcher
IN3546R Stereo Audio Switcher - Featuring 6 Inputs and 1 Output, the
IN3546R adds stereo audio -follow-video capabilities to IN3500 Series
Switchers. The IN3546R attaches to the IN3500 Series I/O port and receives
both power and switching commands from the control port.
Control
IN3590 Wired Remote Control with 25' Long Cable. Allows Remote Channel
Selection for IN3500 Series Switchers
