36 DXP DVI Pro and DXP HDMI Series • Remote Control
Accessing the HTML Pages
Another way to operate the switcher is via its factory-installed
HTML pages, which are always available and cannot be erased or
overwritten. The switcher HTML pages are accessible through its
LAN port, connected via a LAN or WAN, using a web browser such as
Microsoft
® Internet Explorer ® (see
d
Ethernet port in the "Setup"
section for connection information).
Loading the Start-up Page
NOTE: If your Ethernet connection to the matrix switcher is
unstable, try turning off the proxy server in your web
browser as follows:
1. In Microsoft Internet Explorer, click Tools > Internet
Options > Connections > LAN Settings.
2. Clear the Use a proxy server... check box.
3. Click OK.
For details on operating the switcher via HTML pages,
see the DXP DVI, DXP DVI Pro, and DXP HDMI Series User
Guide, “HTML Operation” section.
1. Open the web browser.
2. In the browser address field, enter the DXP IP address.
NOTE: 192.168.254.254 is the factory-specified default value
for this field.
3. Press the keyboard key.
4. If the switcher is not password protected, it checks and
downloads the HTML start-up page.
If the switcher is password protected, the Enter Network
Password window opens.
NOTE: A User name entry is optional.
