APPLICATION DIAGRAM C:
Contact Closure to Serial Command Conversion
CTL101 CONTROL INTERFACE
TECHNICAL SUPPORT:
EXT
INT
SENSOR
MODE
(800) 882-7117
(714) 921-4100
www.inlineinc.com MADE IN U.S.A
IR SENSOR
INPUT
C O N T A C T C L O S U R E I R
O U T
+ –
FUSE: 0.250A; 250V; TIME DELAY
90-260VAC; 0.05A; 47-63Hz
CTL101
Back View
RS232 or RS422 or RS485
contact closure sources
IN3590
Wired Remote
IN9360 Module
With Switch
Switch IN9471 Module
With Double
Throw Switch
= Serial Control
= Contact Closure
= Power
serially controlled devices
IN1404 Video / RGB Video Scaler
with RS-232 Serial Control Port
IN31608–6 Presentation Switcher
with RS-232 Serial Control Port
A/C
Power
Source
