1
©2001 - INLINE, Inc. CIA112 Operation Manual - V1.3 01/31/01
Product Overview
DESCRIPTION
The CIA112 is a high-performance computer interface for analog video and stereo audio signals. The
unit is compatible with a variety of analog video signals including VGA, SVGA, XGA, SXGA,
UXGA, MAC, SUN and other high-resolution workstations. The CIA112 combines a two-input high-
resolution computer video interface and modular A/V connector plates into a versatile unit that fits
neatly in a three gang junction box, and installs quickly in walls, podiums, conference tables or other
audiovisual / presentation furniture. Like other INLINE interfaces, the CIA112 performs the following
functions:
•
Signal Splitting - allows the simultaneous connection and viewing of both the computer’s
local monitor and a second output device such as an LCD data projector or a presentation
monitor.
•
Physical Interfacing - Because computers employ many different types of video output
connectors it is sometimes difficult to directly connect them to data projection devices. The
CIA112 simplifies interfacing tasks by acting as a universal adapter. Through the use of
removable input cables, the CIA112 can be attached to different computers and will provide a
video output signal on five BNC connectors. The output signal may be set to RGBHV
(default), RGBS or RGsB formats.
The CIA112 is not a scan converter. The data projector, monitor or other
output device must be compatible with the horizontal scan rate, vertical
scan rate and resolution output by the computer video card.
PRODUCT FEATURES
•
15-Pin HD VGA Standard Connectors - The CIA112 connects directly to PC, MAC and
SGI graphics ports and local monitors using high-resolution coaxial VGA extension / adapter
cables.
•
Two Inputs with Three Switching Modes - Manual Mode allows users to select the desired
input by pressing the front panel input select button. Remote Switching allows users to select
inputs via any device that is capable of latching contact closure. Autoswitch Mode
automatically selects the active input.
•
Stereo Audio Switching - The CIA112 features dual stereo input connectors that accept
unbalanced stereo audio from computer sound cards, and can output either a balanced or
unbalanced signal.
•
Ultra High-Resolution Amplification - The CIA112 provides superb performance with
analog video signals at any resolution.
•
Selectable Output Sync Format - The unit can be set for RGBHV (default), RGBS or RGsB
output sync as required by the data display device and signal distribution system.
•
Buffered Local Monitor Output - ensures the highest quality display on a local monitor.
•
New Soft-Touch Rocker Button for Horizontal Position Control - allows precise centering
of the image within the data display area.
•
One-Button Monitor Emulation - makes it easy to use the interface without a local monitor.
•
400 MHz Bandwidth
