68-2451-50
Rev. C
05 14
Extron Headquarters
+800.633.9876 Inside USA/Canada Only
Extron USA - West
Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX
+1.919.850.1001 FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
© 2014 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners. www.extron.com
Installation Checklist
Planning (page 1)
† Check with local and state regulations before starting the installation.
† Check all parts and equipment before installation.
Preparing the Table (page 2)
† Determine the best location for the enclosure.
† Choose a method for cutting the hole in the table.
Preparing the Cable Cubby (page 3)
† Choose between AAPs, cable-pass through, and retractor connectivity to populate the Cable Cubby.
† Secure the brackets and power module in the Cable Cubby.
Mounting the Cable Cubby in the Table (page 4)
† Mount the Cable Cubby flush with the table.
Mounting Retractors Under the Table (page 5)
Routing and Connecting Cables (page 6)
Routing and Connecting Cables
For cable pass-through applications,
allow at least 36 inches (0.9 m) of cable
loop for each cable.
Connect cables to the AV system
and connect the AC power cord.
Using zip ties, secure cables to the holes
on the bottom of the Cable Cubby.
1
2
3
CAUTION:
Risk of Electric Shock.
This equipment must be grounded.
ATTENTION:
Risque de choc électrique.
Cet équipement doit être fixé au sol.
NOTE: Ensure that there is no tension on the power cable.
