Cable Cubby 1200 and 1400 • Installation Guide (Continued)
2
Preparing the Table
Cut a hole in the surface where the enclosure will be installed. Read the following information before making a cut.
Determine the best location for the enclosure
Ensure that the location where the Cable Cubby is to be installed is convenient for as many users as possible.
Ensure that the edge on which the lid opens is oriented correctly.
Ensure that there is ample space under the table for cables.
When installing retractors in the Cable Cubby, ensure that there is enough space for the retractor assembly under the table or
furniture. See dimensions for the retractors below.
Choose a method for cutting the hole in the table
ATTENTION: The opening in the table for the Cable Cubby should be cut only by licensed and bonded craftspeople.
Exercise care to prevent scarring or damaging the furniture.
ATTENTION: L’ouverture dans la table pour le Cable Cubby devrait être coupée seulement par des artisans autorisés et
qualifiés. Faites attention à ne pas faire de marques sur le meuble et à ne pas l’endommager.
CAUTION: Wear safety glasses when operating power equipment. Failure to comply can result in eye injury.
ATTENTION: Portez des lunettes de sécurité lorsque vous utilisez l’équipement électrique. Ne pas respecter cela peut
conduire à une blessure à l’oeil.
Choose one of the following methods for cutting the hole:
Hand Router and Routing Template Jigsaw and Paper Cut-Out Template CNC Wood Router
If using a CNC wood router or other
precise machinery, use the exact
cut-out dimensions for your model
(see the table below).
Visit www.extron.com for Cable Cubby routing
template part numbers and instructions.
Dimensions and cut-out templates are
available online at
www.extron.com .
Product
Cut-out Dimensions
User Access
Width
Side
Dimension
CC 1200 10.00"
(254.0 mm)
4.00"
(101.6 mm)
CC 1400 10.00"
(254.0 mm)
6.75"
(171.5 mm)
23.5"
(59.7 cm)
29.4"
(74.7 cm)
26.7"
(67.8 cm)
10.6"
(26.9 cm)
30
Table Top
17.8"
(45.2 cm)
23.7"
(60.2 cm)
XL Models
9.2"
(23.4 cm)
14.9"
(37.8 cm)
20.8"
(52.8 cm)
XL Models
Cut-Out
Template
for the E
xtron
Cab
le C ubb
y 1200
Outer Edg
e of Front Be
zel
(Do not cu
t this lin
e.)
1. Confirm th
e pr oduct to be in
stalle d.
2. Remo ve the surface
cut- out area
(gra y) from the t
emplate
.
3. Measure
the cutout a
nd temp
late .
4. Mark th
e posi tion on th e
fu rnitu re w here the C able Cub by 1200
w ill be installe
d.
5. D oub le ch eck the d
imension
s and p
osition,
then cut the openin
g. Trim Ring Lip
Cut-O ut R adiu s:
0.25 " (0 .6 cm )
User Acce
ss
P/N 68-
2472-01
Re v. A
Pag e Siz
e: 11" x 1
7"
Print Scal
e 1: 1
Do not Shrin
k
