Top View
16
SYSTEM 5000™ HARDWARE
Primary access to the System 5000™ Software is managed through the ¼ VGA touch screen display
on top of the unit. The Power and Active LEDs as well as the SD Card slot are all centrally located
around the display.
Top View
The “Power” LED
blinks every five
seconds while power
is applied to the unit.
The “Active” LED
illuminates when the
unit is collecting data
or performing other
background tasks.
¼ VGA color
TFT touch
screen display
is used to
view and edit
the system
settings and
configuration.
The SD memory card
slot is used to transfer
data and other files to
and from the System
5000™.
