ProLab 4000 Commissioning
27 ba75646e03 12/2012
3.6.1 Connecting an ID sensor
ID sensor with
temperature sensor
ID sensor without
temperature sensor
1 Connect the temperature sensor of the ID sensor to the socket.
2 Connect the ID sensor to the socket of the meter.
The sensor is automatically assigned.
The channel to which is was assigned shows the measurement
data of the sensor.
1 Connect the ID sensor to the socket of the meter.
As soon as the meter has recognized the ID sensor, the Auto-
matic sensor recognition window appears with the sensor
name and series number.
2 Assign the sensor that was recognized to a channel with pH/U/
ISE Probe 1 or pH/U/ISE Probe 2.
As soon as a sensor was assigned to a channel, the assign-
ment is completed and the Automatic sensor recognition is
closed again.
Note
The manual assignment of a sensor to a channel is stored in the
meter. The next time the meter is switched on while ID sensors are
connected, the last assignment of the sensor is displayed and can be
confirmed with .
