1.2

CURRENT SENSING
This is accomplished by inserting one common

power conductor through a linear output Hall effect

doughnut.

1.3

VOLTAGE SENSING
This is accomplished with a resistor network and a

potential transformer. Maximum voltage level is 600V

RMS.

1.4

CALIBRATION
Calibration is performed at the factory for all ranges

of current and voltage. This resides in the EEPROM

on board the PTB.

1.5

APPLICATION
The following is performed by the factory. However, if

a PTB is being replaced in the field the following must

be observed:
A. One common (to load) conductor must be run

through the doughnut.
NOTE: This conductor must not rest on the PTB

components except for the current transformer.

Arc the wire, in order to bias it away from the PTB,

before inserting it in the current transformer.

Secure in place with wire ties.

B. Insert this conductor into the hole on the flat side

of the doughnut with the load side of the conduc-

tor coming out of the opposite side of the hole.

C. 3 Phase – connect all 3 phases to terminals of J1

marked AØ, BØ, and CØ. Do not use com. AØ

must also be the same phase as that inserted into

the doughnut. Which is AØ, BØ or CØ is arbitrary

but must be established to follow these rules.

Single Phase – connect the “hot” line to AØ only

and neutral to com. Again AØ phase must be the

same phase as inserted into the doughnut.

D. Move voltage jumpers J3 and J6 to a voltage as

close to actual as possible. Jumpers on J3 and J6

must match each other.

E. Move jumper J2 to next highest amp terminal above

total motor load in amps. that may run at one time.

1.6

PHASE CONSIDERATIONS
The PTB will perform well with delta or wye systems,

grounded or ungrounded. However, on 3 phase

grounded systems do not ground the com. terminal

of J1.

1.7

MENU CONSIDERATIONS
A menu entry must be made as to whether this unit

will be used in a 3 phase or 1 phase system.

AUTHORIZED REPRESENTATIVE

Xylem Inc.

10661 Newkirk Street

Dallas, TX 75220

Phone: (469) 221-1200

Fax: (214) 357-5861

www.xyleminc.com/brands/bellgossett

Bell & Gossett is a trademark of Xylem Inc. or one of its subsidiaries.
© 2012 Xylem Inc. S12228B August 2012
