4.5.2

ALARMS

ALARMS

CONDITION

HELP MESSAGE

Overload X Failure

Check AMP draw, use manual reset if OK

High Suction PSI

High suction pressure – check suction
pressure and trip point

Low Suction PSI

Low suction detected – check suction
pressure and trip point

High System PSI

High pressure detected in the system –
check trip point

Low System PSI

Low pressure detected in the system –
check PRV and set point

Water Level Low

Check water level in holding tank

Water Temp High

Check water temperature

Pump X Off

Need pump in system – if OK enable pump

Suction Trans Fail

Check wiring, piping, polarity, and continuity

System Trans Fail

Check wiring, piping, polarity, and continuity

Flow Trans Fail

Check wiring, piping, polarity, and continuity

Suction RTD1 Fail

Check wiring, continuity

System RTD2 Fail

Check wiring, continuity

Power Fail

Check cable connections and plug insertions

Pump X Failure

Check DP switch, impeller, coupler, motor

Remote Contact Open

7 Day Timer Off

NOTES:

Bottom line only. No help message.
