10

Default

Allowable

Field

Line #

DISPLAY

Value

Range

Values

12

Pump 2 AMPs 0
Enter Motor #2 nameplate FLA

0

0 - 175

13

Pump 3 AMPs 0
Enter Motor #3 nameplate FLA

0

0 - 175

14

Pump #1 GPM 0
Enter Staging GPM of Pump #1

0

0 - 30,000

15

Pump #2 GPM 0
Enter Staging GPM of Pump #2

0

0 - 30,000

16

Pump #3 GPM 0
Enter Staging GPM of Pump #3

0

0 - 30,000

17

1 - 2 Stage % 80
Enter percent of NPHP, NPFLA, or GPM to stage 2nd
pump in sequence

80

0 - 100

18

2 - 3 Stage % 80
Enter percent of NPHP, NPFLA or GPM to stage 3rd
pump in sequence

80

0 - 100

19

Destage % 90
Enter percent of stage percent for destaging with HP,
AMPs, or GPM only

90

0 - 99

20

Staging PSI 0
Enter pressure to stage in PSI mode after entering system

0

0 - System Span

pressure span (see Line 38)

21

Destaging PSI
Enter pressure to destage in PSI mode after entering system

0

0 - System Span

pressure span (see Line 38)

22

Forced Destg Tmr. 60
Enter in minutes (0 - 99) value of a timer after which the

60

0 - 99

pump will be forced to de-stage; ‘0’ disables this function

23

GPM Xmiter Span
Enter value equal to GPM transmitter calibration

0

0 - 30,000

24

2nd Stage Proof 2
2nd pump stage proof time in seconds

5

1 - 180

25

3rd Stage Proof 2
3rd pump stage proof time in seconds

5

1 - 180

26

Display Watts YES
Use up/down keys to enter yes or no

Yes

Y/N

27

Three phase Watts YES
Use up/down keys to enter yes or no, YES = three phase,

Yes

Y/N

NO = single phase

28

Display AMPs YES
Use up/down keys to enter yes or no

Yes

Y/N

29

Display GPM No
Use up/down keys to enter yes or no

No

Y/N

30

Suction Press. Span 100
Enter value equal to suction pressure span

100

0 - 999

31

High Suct. Press. 0
Enter value of the high suction pressure above which an

0

0 - 100

alarm will be set

32

High Suct. Pr. TMR. 0
Enter in seconds (0 - 999) value of high suction cutout

0

0 - 999

proof timer, ‘0’ disables this function

33

High Suct. Reset 0
Enter value of the high suction reset pressure

0

0 - 100

34

Low Suct. Press. 5
Enter value of the low suction pressure below which an

5

0 - 100

alarm will be set

35

Low Suct. Pr. TMR. 20
Enter in seconds (0 - 999) value of low suction proof timer;

20

0 - 999

‘0’ disables this function

36

Low Suct. Reset 10
Enter value of the low suction reset pressure

10

0 - 100
