70E/70M Pressure Booster
INSTRUCTIONS
UNIT IDENTIFICATION
The unit nameplate gives identification and rating information as identified in Figure 1.
Permanent records for this unit are kept by the factory number and
it must therefore be
used with all correspondence and spare parts orders.
Model No.
Factor no.
Wired for Volts Hz Ph
System FL Amps
Largest Motor HP
System Flow GPM
Suction Pressure PSIG
Discharge Pressure PSIG
Pump TDH Feet
Date Code
FIGURE 1 - 70E/70M NAMEPLATE
