SMVT Product Line Numbering System
The various versions of the SMVT line are identified by a product code number on the pump label.
This number is also the catalog number for the pump. The meaning of each digit in the product
code number is shown below. Note: Not all combinations are possible. Consult your Goulds Water
Technology distributor.
Example Product Code: SM3A1J2C1VA
Appendix
BEP
Flow
Product 60 Hz
Line (50 Hz) Material Hz/RPM HP Driver Stages Seal Options Trim
A Trim B Trim C Trim
D Trim E Special Trim
V = Vertical Mount
H = Horizontal Mount
1 = Standard 2B Crane Seal
A = 1, B = 2, C = 3, D = 4,
E = 5, F = 6, G = 7, H = 8,
J = 9, K = 10, L = 11, M = 12
1 = 1 PH ODP,
2 = 3 PH ODP,
3 = 3 PH 575 V ODP,
4 = 1 PH TEFC,
5 = 3 PH TEFC,
6 = 3 PH 575 V TEFC,
7 = 3 PH 415 V ODP,
8 = 3 PH 415 V TEFC
A = 3 HP, B = 5 HP, C = 7.5 HP,
D = 10 HP, E = 15 HP, F = 20 HP,
G = 25 HP, H = 30 HP, J = 40 HP,
K = 50 HP, L = 60 HP, M = 75 HP
1 = 60 Hz, 3600 RPM;
2 = 50 Hz, 3000 RPM
A = Standard construction
with carbon steel casing
D = Standard construction
with stainless steel casing
1 = 175 GPM (33 m 3 /hr),
2 = 230 GPM (45 m 3 /hr),
3 = 380 GPM (72 m 3 /hr),
4 = 480 GPM (91 m 3 /hr),
5 = 600 GPM (114 m 3 /hr),
6 = 700 GPM (133 m 3 /hr)
SM = SMVT
